Single row angular contact ball bearing
Category：
Angular Contact Ball Bearings
Single Row Angular Contact Ball Bearings
Single row angular contact ball bearings are mainly used in situations where both radial and axial combined loads are withstood, and sometimes they can also withstand pure axial loads, with higher rotational speeds.
The material of bearing ring parts shall be high一quality refined bearing steel GCR15 and other grades of bearing steel, and the rolling body shall be made of GCR15 bearing steel or ceramic.
According to different contact angles, bearings can be divided into three types: 7000C (15 °), 7000AC (25 °), 7000AA (26 °), and 7000B (40 °). Bearings with different contact angles can be produced according to user requirements.
Product parameter
型号 Designation | 基本尺寸（mm） Principal Dimensions | 额定负荷（KN） Basic Load Ratings | 极限转速（rpm） Limited Speed | 重量 | |||||
|
| d | D | B | 动负荷 | 静负荷 | 脂润滑 | 油润滑 | Mass(Kg) |
7800C | 一 | 10 | 19 | 5 | 一 | 一 | 一 | 一 | 0.005 |
7000C | 一 |
| 26 | 8 | 4.9 | 2.1 | 24000 | 32000 | 0.019 |
7000AC | 一 |
| 26 | 8 | 4.7 | 2.1 | 24000 | 32000 | 0.019 |
7200C | 一 |
| 30 | 9 | 5.8 | 2.9 | 22000 | 28000 | 0.032 |
7200AC | 一 |
| 30 | 9 | 5.5 | 2.8 | 22000 | 28000 | 0.032 |
7200B | 7200AA |
| 30 | 9 | 5.3 | 2.7 | 19000 | 27000 | 0.030 |
7300C | 一 |
| 35 | 11 | 9.8 | 4.6 | 18000 | 26000 | 0.053 |
7300AC | 一 |
| 35 | 11 | 9.5 | 4.4 | 18000 | 26000 | 0.053 |
7801C | 一 | 12 | 21 | 5 | 一 | 一 | 一 | 一 | 0.006 |
7901C | 一 |
| 24 | 6 | 3.3 | 1.8 | 28000 | 36000 | 0.011 |
7901AC | 一 |
| 24 | 6 | 3.2 | 1.7 | 28000 | 36000 | 0.011 |
7001C | 一 |
| 28 | 8 | 5.4 | 2.6 | 22000 | 28000 | 0.021 |
7001AC | 一 |
| 28 | 8 | 5.1 | 2.4 | 22000 | 28000 | 0.021 |
7201C | 一 |
| 32 | 10 | 7.9 | 3.8 | 20000 | 25000 | 0.037 |
7201AC | 一 |
| 32 | 10 | 7.6 | 3.6 | 20000 | 25000 | 0.037 |
7201B | 7201AA |
| 32 | 10 | 6.9 | 3.2 | 18000 | 24000 | 0.036 |
7301C | 一 |
| 37 | 12 | 11.8 | 5.6 | 17000 | 24000 | 0.060 |
7301AC | 一 |
| 37 | 12 | 11.5 | 5.4 | 17000 | 24000 | 0.060 |
7301B | 7301AA |
| 37 | 12 | 10.5 | 4.9 | 16000 | 22000 | 0.060 |
7802C | 一 | 15 | 24 | 5 | 一 | 一 | 一 | 一 | 0.007 |
7902C | 一 |
| 28 | 7 | 4.7 | 2.6 | 24000 | 32000 | 0.015 |
7902AC | 一 |
| 28 | 7 | 4.5 | 2.5 | 24000 | 32000 | 0.015 |
7002C | 一 |
| 32 | 9 | 6.2 | 3.3 | 19000 | 25000 | 0.030 |
7002AC | 一 |
| 32 | 9 | 5.9 | 3.2 | 19000 | 25000 | 0.030 |
7202C | 一 |
| 35 | 11 | 9.2 | 4.9 | 17000 | 22000 | 0.045 |
7202AC | 一 |
| 35 | 11 | 8.9 | 4.8 | 17000 | 22000 | 0.045 |
7202B | 7202AA |
| 35 | 11 | 7.9 | 4.2 | 16000 | 22000 | 0.045 |
7302C | 一 |
| 42 | 13 | 13.2 | 6.7 | 15000 | 21000 | 0.084 |
7302AC | 一 |
| 42 | 13 | 12.5 | 6.2 | 15000 | 21000 | 0.084 |
7302B | 7302AA |
| 42 | 13 | 12.4 | 6.5 | 14000 | 19000 | 0.080 |
