Home page

DU series hub bearing

Category：

Wheel Hub Bearings

+86-13734458000

info@drnbearings.com

E-mail

Wheel Hub Bearings

The main function of hub bearing is to bear weight and provide accurate guidance for the rotation of the hub. It bears both axial load and radial load, and is a very important component. The traditional automobile wheel bearing is composed of two sets of tapered roller bearings or ball bearings. The installation, oiling, sealing and clearance adjustment of the bearings are carried out on the automobile production line. This structure makes it difficult to assemble in the automobile factory, with high cost and poor reliability. In addition, when the automobile is maintained at the maintenance point, the bearing needs to be cleaned, oiled and adjusted. Hub bearing unit is developed on the basis of standard angular contact ball bearing and tapered roller bearing. It combines two sets of bearings as a whole. It has the advantages of good assembly performance, can omit clearance adjustment, light weight, compact structure, large load capacity, can be filled with grease in advance for sealing bearings, can omit external hub seal and is free from maintenance. It has been widely used in cars, and has the trend of gradually expanding its application in trucks.

Bearing Number	JAPAN(KOYO)	GERMANY(FAG)	SWEDEN(SKF)	JAPAN(NSK)	Dimension(mm)
Bearing Number	JAPAN(KOYO)	GERMANY(FAG)	SWEDEN(SKF)	JAPAN(NSK)	d	D	B	C
DAC12280012					12	28	12	12
DAC124000183			C-00187		12	40	18.3	18.3
DAC20420030/29		565592	56592J22		20	42	30	29
DAC205000206		156704			20	50	20.6	20.6
DAC205000206		320104			20	50	20.6	20.6
DAC2184800206/18				CBK506	21.8	48	20.6
DAC254650027/24					25.4	65	27
DAC255200206/23				VBF 256705	25	52	20.6
DAC25520037S				FC12025	25	52	37
DAC255200206			617546A		25	52	20.6	20.6
DAC25520032					25	52	32	32
DAC25520037		546467/576467	BT2B445539CC		25	52	37	37
DAC25520037		546467/576467	VKBA869		25	52	37	37
DAC25520040					25	52	40	40
DAC25520042	DAC2552W-4CS25			25BWD01	25	52	42	42
DAC25520043					25	52	43	43
DAC25520045/43					25	52	45	43
DAC25550043					25	55	43	43
DAC25550045					25	55	45	45
DAC25560029/206			BA2B633280		25	56	29	20.6
DAC25560032		445979	BAH500		25	56	32	32
DAC25600029/206			BA2B633272		25	60	29	20.6
DAC25600045					25	60	45	45
DAC25620028/17					25	62	28	17
DAC25620048					25	62	48	48
DAC25720043					25	72	43	43
DAC27520045					27	52	45
DAC27520045/43		801437		27KWD02	27	52	45	43
DAC27520050					25	52	50	50
DAC27530043					27	53	43	43
DAC27600050			FW120	27BWD01J	27	60	50	50
DAC28580042	DAC2858W	576447		28BWD03ACA51	28	58	42	42
	DAC2858RKCS47
	DAC28582RK
DAC28580044					25	58	44	44
DAC28590038/28					28	59	38	28
DAC28610042	DAC286142AWCS40		VKBA1346	28BWD01ACA60	28	61	42	42
DAC29530037		801023AB	VKBA3531		29	53	37	37
DAC29530037		801023AB	BTH1206AA		29	53	37	37
DAC30500020					30	50	20
DAC30520042					30	58	42
DAC30540024					30	54	24	24
DAC30550026				30BWD08	30	55	26	26
DAC30550030/25	ATV-BB-2				30	55	30
DAC30550032	DAC3055WCS31				30	55	32	32
DAC30580042			VKBA1349	30KWD01AG3	30	58	42	42
DAC30600037	DAC3060372RS	545312A	BAHB63313CA		30	60	37	37
		529891AB
		522372
DAC30600337	DAC3060W	529891AB	BA2B633313CA	30BWD07	30	60.3	37	37
		545312	418780
		581736	405956A
			434201B
			VKBA1307
DAC30600037/34				BA2B243739CA	30	60	37
DAC30600043/37					30	63	43	37
DAC30620032				30BVV06	30	62	32
DAC30620037					30	62	37
DAC30620038				30BWD10	30	32	38	38
DAC30620044					30	62	44
DAC30630042	DAC3063W-1			30BWD01A	30	63	42
DAC30640037					30	64	37
DAC30640042				30BWD03ACA78	30	64	42	42
	DAC3064W2RKBCS8
	DAC3064WRKB
DAC30650021		522372		630374/C4	30	65	21
DAC306500264				320406	30	65	26.4	26.4
DAC30670024			361971		30	67	24	24
DAC30680045				30BWD04CA19	30	68	45	45
DAC307200302		3306			30	72	30.2
DAC30720037				BAHB636035	30	72	37
DAC32700038					32	70	38	38
DAC32720045				32BWD05	32	72	45
DAC325800065/57					32	58	65
DAC32720034					32	72	34	34
DAC32720045				32BWD06	32	72	45	45
DAC32720345				32BWD05P5A	32	72.03	45	45
DAC32730054	DAC3273W				32	73	54	54
DAC34620037	DAC34620037	531910	BAHB311316B		34	62	37	37
DAC34620037	DAC34620037	561447	309724		34	62	37	37
DAC34640034	DAC3464D		VKBA1382	34BWD03ACA78	34	64	34	34
DAC34640037	DAC3464G	532066DE	605214	34BWD04BCA70	34	64	37	37
	12RSCS42	540466B	VKBA1306	34BWD11
	DAC3464W-2RS	805231	BA2B309726
			309726DA
DAC34660037		559529/580400CA	636114A/479399	34BWD10B	34	66	37	37
DAC34670037					34	67	37	37
DAC34680037	DAC3468DW			34BWD08A	34	68	37	37
DAC34740037					34	74	37	37
DAC34740040					34	74	40	40
DAC356180031					35	61.8	31
DAC356180040	DAC3562W				35	61.8	40	40
DAC35620031	DAC3562AW				35	62	31	31
DAC35620037					35	62	37	37
DAC35620040					35	62	40	40
DAC35640037	DAC3564A-1		BAH0042		35	64	37	37
DAC35650035	DAC3565WCS30	546238A	443952		35	65	35	35
			BT2B445620B
			VKBA3496
			VKBA1413
DAC35650037				35BWD19E	35	65	37	37
DAC35660032	DAC3566		445980A/BAH5001A		35	66	32	32
DAC35660033			633676/BAH-0015		35	66	33	33
DAC35660037	DAC35660037	544307CD/581010A	BAHB311309		35	66	37	37
DAC35660037	DAC35660037	544307CD/581010A	BAH0023		35	66	37	37
DAC35670042				35BWD24	35	67	42	42
DAC35680037	DAC3568A2RS	567918B	BAHB311309	35BWD21(4RS)	35	68	37	37
		541153A	633697
		430042C	BAHB633295B
		549676	633528F(ZZ)
			VKBA1315
DAC35680039/36					35	68	39	36
DAC35680042					35	68	42	42
DAC35680045					35	68	45	45
DAC35680048					35	68	48	48
DAC35680233/30	DAC3568W6CS48		VKBA1342	35BWD07A	35	68.02	33	30
DAC35720027					35	72	27	27
DAC35720228		544033	BA2B441832AB		35	72.02	28	28
DAC35720033	DAC357233B	548083	BA2B446762B	XGB 40714	35	72	33	33
			BA2B445535AE
			456162
			446762
			VKBA882
			VKBA1327
DAC35720233/31	DAC357233B-1W	562686	FWB141	35BWD06ACA111	35	72.02	33	31
DAC35720233/31	DAC357233B-1W	562686	VKBA1343	35BWS08A	35	72.02	33	31
DAC35720433	DAC357545CW2R		BAHB633669/BAH0013		35	72.04	33	33
DAC35720034	DAC357234A	540763/548376A	VKBA857	35BWD01	35	72	34	34
DAC35720434			BAH0013D		35	72.04	34	34
DAC35720042					35	72	42	42
DAC35720045					35	72	45	45
DAC35740030				3507DTN	35	74	30	30
DAC35760054				35BWD10	35	76	54	54
DAC35770042	DAC3577W-2		VKBA3763		35	77	42	42

Product features:

factory

with an advantageous geographical location and convenient transportation.Our factory founded in 2008,foreign brand image, internal constant pursuit of technological innovation and scientific management, constantly optimize the product structure and production structure, is committed to explore new areas, has been the development, design, Product quality continues to improve, and products continue to improve.

Customer visit

The company mainly produces auto wheel bearings and wheel hub bearing and repair kits, widely used at home and abroad hundreds of high-end models.

Packaging and delivery

Linqing Huizhi Bearing Co., Ltd. is located in Yandian Town, Linqing City, the hometown of bearings in China, with a total construction area of more than 5,000 square meters.

FAQ

Q: What are your payment terms?

A: Payment <= 1000 USD, 100% USD in advance. Payment > = $1000, 30% T/T in advance, balance before delivery.

Q: Do you provide samples? Is it free or extra?

A: Yes, we can provide samples free of charge, but we don't pay for shipping.

Q: What is your lead time?

A: If the goods are in stock, it is usually 5-10 days. Or, if the goods are not in stock, then 15-20 days, it is based on quantity.

Q: Are you a trading company or a manufacturer?

A: We are a factory!

Q: Can you provide door to door service?

A: Yes, by express (GHL, FEDEX, TNT, EMS, 4-10 days to your city.)

Q: Are you a corporate factory or a trading company?

A:We have our own factory; Our type is factory + trade.
