Self-aligning ball bearing is a bearing equipped with spherical ball between the inner ring of two raceways and the outer ring of spherical raceways. The curvature center of the outer ring raceway surface is consistent with the bearing center, so it has the same self-aligning function as the self-aligning ball bearing. When the shaft and shell are bent, they can be adjusted automatically without increasing the bearing burden. Self-aligning roller bearing can bear radial load and axial load in two directions. Large radial load capacity, suitable for heavy load and impact load. The inner diameter of the inner ring is a bearing with a tapered hole, which can be installed directly. Or install it on the cylindrical shaft with a set sleeve and a disassembly cylinder. The cage is made of steel plate stamping cage, polyamide forming cage and copper alloy turning cage.

Category：

Self-aligning Ball Bearings

+86-13734458000

Whatsapp

info@drnbearings.com

E-mail

Related Products
Message

Self-aligning ball bearings

Self-aligning ball bearing is a bearing equipped with spherical ball between the inner ring of two raceways and the outer ring of spherical raceways.
The curvature center of the outer ring raceway surface is consistent with the bearing center, so it has the same self-aligning function as the self-aligning ball bearing. When the shaft and shell are bent, they can be adjusted automatically without increasing the bearing burden. Self-aligning roller bearing can bear radial load and axial load in two directions. Large radial load capacity, suitable for heavy load and impact load. The inner diameter of the inner ring is a bearing with a tapered hole, which can be installed directly. Or install it on the cylindrical shaft with a set sleeve and a disassembly cylinder. The cage is made of steel plate stamping cage, polyamide forming cage and copper alloy turning cage.

轴承型号 基本尺寸／mm 基本额定载荷／KN 极限转速（r／min） 重量／kg
新型号 旧型号 d D T Cr动 Cor静 脂 油 W≈
2200 1500 10 30 14 7.4 1.6 23000 29000 0.047
2201 1501 12 32 14 7.65 1.75 21000 26000 0.053
2202 1502 15 35 14 7.7 1.85 18000 22000 0.06
2203 1503 17 40 16 9.8 2.4 16000 20000 0.088
2204 1504 20 47 18 12.6 3.3 14000 17000 0.14
2205 1505 25 52 18 12.6 3.3 12000 15000 0.163
2206 1506 30 62 20 15.6 4.65 10000 12000 0.26
2207 1507 35 72 23 21.6 6.6 8500 10000 0.403
2208 1508 40 80 23 22.5 7.4 7600 9300 0.505
2209 1509 45 85 23 23.3 8.15 7000 8500 0.545
2210 1510 50 90 23 23.3 8.5 6500 7900 0.59
2211 1511 55 100 25 26.8 10 5800 7100 0.81
2212 1512 60 110 28 34.1 12.6 5300 6500 1.09
2213 1513 65 120 31 43.5 16.4 4900 5900 1.46
2214 1514 70 125 31 44 17 4500 5600 1.62
2215 1515 75 130 31 44.2 17.8 4300 5300 1.71
2216 1516 80 140 33 49 19.9 4100 5000 2.01
2217 1517 85 150 36 58.3 23.6 3800 4600 2.52
2218 1518 90 160 40 67.7 27.2 3500 4300 3.4
2219 1519 95 170 43 82.7 34.3 3300 4000 4.1
2220 1520 100 180 46 80.9 34 3100 3800 4.98
2221 1521 105 190 50 94.9 40.1 3000 3600 6.07
2222 1522 110 200 53 124 52 2800 3400 7.16
2224 1524 120 215 58         8.19
2226 1526 130 230 64         10.2
2228 1528 140 250 68         12.9
2230 1530 150 270 73         16.3

Product features:

Self-aligning ball bearing is a bearing equipped with spherical ball between the inner ring of two raceways and the outer ring of spherical raceways.
The curvature center of the outer ring raceway surface is consistent with the bearing center, so it has the same self-aligning function as the self-aligning ball bearing. When the shaft and shell are bent, they can be adjusted automatically without increasing the bearing burden. Self-aligning roller bearing can bear radial load and axial load in two directions. Large radial load capacity, suitable for heavy load and impact load. The inner diameter of the inner ring is a bearing with a tapered hole, which can be installed directly. Or install it on the cylindrical shaft with a set sleeve and a disassembly cylinder. The cage is made of steel plate stamping cage, polyamide forming cage and copper alloy turning cage.

factory

with an advantageous geographical location and convenient transportation.Our factory founded in 2008,foreign brand image, internal constant pursuit of technological innovation and scientific management, constantly optimize the product structure and production structure, is committed to explore new areas, has been the development, design, Product quality continues to improve, and products continue to improve.

factory

Customer visit

The company mainly produces auto wheel bearings and wheel hub bearing and repair kits, widely used at home and abroad hundreds of high-end models.

Customer visit

Packaging and delivery

Linqing Huizhi Bearing Co., Ltd. is located in Yandian Town, Linqing City, the hometown of bearings in China, with a total construction area of more than 5,000 square meters.

Packaging and delivery

FAQ

Q

Q: What are your payment terms?

A
A: Payment <= 1000 USD, 100% USD in advance. Payment > = $1000, 30% T/T in advance, balance before delivery.
Q

Q: Do you provide samples? Is it free or extra?

A
A: Yes, we can provide samples free of charge, but we don't pay for shipping.
Q

Q: What is your lead time?

A
A: If the goods are in stock, it is usually 5-10 days. Or, if the goods are not in stock, then 15-20 days, it is based on quantity.
Q

Q: Are you a trading company or a manufacturer?

A
A: We are a factory!
Q

Q: Can you provide door to door service?

A
A: Yes, by express (GHL, FEDEX, TNT, EMS, 4-10 days to your city.)
Q

Q: Are you a corporate factory or a trading company?

A
A:We have our own factory; Our type is factory + trade.
